Directional Drilling

Rotary Steerable Systems

Automated rotary steerable systems with German engineering, built for precise well placement and efficient drilling, onshore and offshore.

Contact an expert

Autonomous drilling

Designed to drill the reservoir autonomously

Our systems drill the reservoir autonomously. Once the target is set, closed-loop control downhole holds inclination and azimuth with fewer adjustments and commands from surface. New commands go down by automated downlink, with the bit on bottom.


Near-bit steering

Readings close to the bit, precise landing on target

Inclination, azimuth and gamma ray are measured close to the bit, so trajectory and formation changes show up quickly and the system adjusts automatically to stay on target within the reservoir.

Rotary steerable system hanging in the derrick before running in hole
Hole sizes covered
6–17½in
Max. rotational speed
400rpm
Max. build-up rate
8°/100 ft
Max. hydrostatic pressure
20,000psi

Advantages

What sets our RSS apart

  • Precise trajectory with fewer commands

    Automatic closed-loop control of inclination and azimuth.

  • Independent hydraulic system

    The push pistons on the non-rotating sleeve need no additional pressure drop.

  • Independent of mud rheology

    The force on the pads does not depend on mud weight, flow rate, pressure drop across the bit or LCM.

  • Easy rig handling

    RSS and MWD integrated in a single tool.

  • Corrections without stopping drilling

    Automated downlink from surface, with the bit on bottom.

  • Freedom to choose the bit

    Works with a wide variety of bits.

  • Precise steering near the bit

    Gamma and directional sensors close to the bit show trajectory and formation changes quickly; parameters adjust automatically.

  • LWD above the RSS

    Resistivity LWD and PWD can be run above the tool.

Our systems

One RSS platform for directional and vertical wells

VectorZIEL is our 3D system for directional, horizontal and S-profile wells; VectorEXAKT is the vertical option. Both share surface downlink, turbine power and MWD telemetry, and are designed and manufactured in Germany, with engineering and repair in Houston.

3D render of the VectorZIEL and VectorEXAKT rotary steerable systems
VectorZIEL rotary steerable system

VectorZIEL

3D rotary steerable system

Automated 3D steering for S and J profiles, horizontal wells and high-precision tangents, onshore and offshore. Push-the-bit design for a smooth, in-gauge hole.

  • Series 400 | 600 | 800
  • Hole 6 to 14½ in

Key features

  • Build, hold and drop back to vertical in one run, with ±0.1° accuracy
  • Near-bit inclination, azimuth and gamma ray; azimuthal gamma optional
  • Drill and enlarge in one run, with a hydraulic reamer in the same BHA
  • Automated downlink with the bit on bottom: 6 min average per command
VectorEXAKT rotary steerable system

VectorEXAKT

Vertical rotary steerable system

The vertical option: automatic verticality control with ±0.1° accuracy up to 17½ in, for mine shafts, critical vertical wells and jack-up rigs subject to movement.

  • Series 800 | 900
  • Hole 12¼ to 17½ in

Key features

  • Integrated MWD telemetry for real-time feedback while drilling
  • Near-bit inclination as standard, with gamma ray LWD as an option
  • Autonomous steering back to vertical when the hole deviates
  • Can run below a motor for near-bit performance drilling
World map with the 28 countries where VectorZIEL and VectorEXAKT have run

Global experience

Proven on five continents

From S-profile sections drilled in a single run to a raise-bore world record and parallel horizontal holes, our systems have run onshore and offshore in oil and gas, mining and infrastructure.

Runs worldwide
240+
Countries with runs
28
